7 x 9cm (2.76"X3.54") Single Side Prototype PCB Panel Universal Circuit Board FR-4 Glass Fiber

Payment Terms:	T/T
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 12674-b

Production Capacity: 10000

Delivery Date: 5 days

Board Thickness: 1.6mm

size: 7*9cm

Min. Hole Diameter: 1mm

Means of Transport: Ocean,Land,Air

Packing: 50 pieces a lot

Copper Thickness: 0.1mm

hole count: ....

material: FR-4

Min. Line Spacing: 2.54mm

Each unit will accept transistors, diodes, LEDS, resistors, capacitors and virtually all types of components.

Features:

Brand new and high quality.
Material: Single Side Copper PCB.
Hole Dia: about 1mm.
Hole pitch: standard 2.54mm.
For point to point DIY soldering.
Size:7cm x 9cm - 1.97inch x 2.76inch.
Quantity:10.

Copper Thickness	0.1mm
Board Thickness	1.6mm
hole count	....
size	57cm~5050cm
material	FR-4
Layer	1-20

produce two layer, four layer, eight layer PCB circuit board and26 layers, and to undertake PCB board independent developmentprogramming. To achieve various functions used in all kinds of household electrical appliances and automotivemanufacturing industry. Also provides revisio serviclife. 50PCS/LOT DIY Prototype Paper PCB Universal Board New #BV050

50PCS/LOT DIY Prototype Paper PCB Universal Board New #BV050

Plate thickness 0.30mm-- 6.0mm, plating thickness is 0.007 (alloy)PCB board

Processing types of single, double-sided board, multilayer board,control all kinds of special requirements of the circuit board (such ashigh-frequency board, aluminum board etc.)

Plate thickness	0.30mm-- 6.0mm
plating thickness	0.007 (alloy)PCB board
The plate	0.3mm-- 3.0mm
The maximum size	670mm × 510mm
Minimum pad diameter	20MIL (0.5mm)
smallest metallized hole	Huankuan 6mil (0.15mm)
minimum diameter of	12mil (0.3mm) forming
minimum Xian Kuan	8mil (0.2mm)
Minimum line gap	8mil (0.2mm)
older resist liquid photosensitive ink	4mil (0.10mm) 8mil (0.20mm)
Shape processing NC milling error	4mil (0.1mm)
CNC drilling location error of	1mil (0.025mm)
Forming hole maximum aperture error	1mil (0.025mm)
The product warp degree	0.7%
