square hole breadboard type SYB-130 from China manufacturer - Cixi Zhongyi Electronic Equipment Factory

Payment Terms:	T/T,L/C,D/A,D/P,WU;PAYPAL
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SYB-130

Production Capacity: 1500000

Delivery Date: 0-3 day after payment

1 Terminal Strip: Tie-point 760

Characteristic: solderless

Pitch: 2.54mm / 0.1'

Package: bulk package

Screw Hole: 4 holes in each corner

Means of Transport: Ocean,Land,Air;DHL

Packing: carton box

board size(cm): 18.9*4.6*0.85

Conductor Type: socket

Back Side: insulating rubber tape

Operating Temperature: -20 ~ +80 centigrade

Contact way: spring clip

board size(cm):18.9*4.6*0.85
1 Terminal Strip,Tie-point 760
It is a simple breadboard without self-adhesive paper, only a piece of insulating tape.

Product Name: 760 points solderless breadboard
      board size(cm): 18.9*4.6*0.85
      1 Terminal Strip, Tie-point 760
      Paper Box;
      1pc/ set

ABS plastic material
Completely reusable
Accepts a variety of wrie sizes (AWG: 20-29)

760 points universal breadboard

In the four right-angle, there is screw hole. With it, you can fix the breadboard on other board or machine strong.

Contact Resistance	100mΩmax
Operating Temperature	-20°C–+80°C
Housing Material	ABS
Contact way	Spring clip
Connector Type	Socket
Plug Time	≥10000 time

Package: this type has no independent package. The package is 25 pieces breadboard packed into a transparent plastic bag. But if you need skin package, we can also do it.

760 points universal breadboard

825 pieces of SYB-130 will be packed into a carton box. Of course, this is our ordinary package. According to different shipping way, we will adopt the most suitable way.

760 points universal breadboard

We are manufacturer. Our factory accept ODM and OEM. So just tell us what you want. Then we will do the best design for you. Of course, if you send us the drawing, it is apreicated.

If you need your own company logo on the product, we can also do.
